SeaBot-Featured

SeaBotix vLBV-300

The vLBV is the latest in highly capable vectored. ROVs offering a stable and powerful platform for a diverse range of applications.



vLBV

  • Six (6) Brushless DC thrusters (4 vectored, 2 vertical)
  • Auto heading, depth and trim
  • Video overlay
  • T emperature sensor

Cameras & Lighting

  • 3 x cameras : 2 x front cameras and 1 back camera
    • Standard camera: 600 line exView color camera – 0.001 lux
    • Main camera : High definition camera
  • the LYYN video enhancer to help correct color real time creating an improved image for the operator.
  • 2 x 1080 Lumen LED arrays tracking color camera

The Tritech Micron scanning sonar

  • Provides sonar coverage at ranges up to 75 meters (252ft)

Tracking System – AAE 310 Micro Beacon with RM90V Transducer

  • Transmit frequency range 25-32.5kHz
  • Receive frequency range 16-26kHz



Tether

  • 250 meters – 820 feet of tether
  • 9 mm – 0.35 in diameter
  • 100 kg f – 220 ft/lb working load
  • 700 kg f – 1,540 ft/lb breaking strain
  • Connectors and strain relief

Integrated Control System

  • Protective case fitted with monitor, surface power supply and operator control unit
  • 38 cm (15 in) Color LCD monitor fitted in lid of case – waterproof
  • vLBV operator control unit – removable from lower tray of integrated console
  • Sunshade for direct sunlight operation

Sonardyne Scout Plus USBL : 2nd tracking system

  • Sonardyne’s Coastal Transponder is our position tracking system.
  • The unit operates in the HF frequency band from 35-55 kHz.
  • Depth rated to 500 Metres
  • Alkaline battery packs give up to 18 months listening life
